PointCab
Point cloud processing made easy
powerful
manage 3D data
For Windows OS
Thanks to the collaboration between Stonex and PointCab, you can try this powerful software with our Laser Scanners.
PointCab Origins is your Swiss army knife when it comes to the evaluation of point cloud data – working with all laser scanners and compatible with all CAD and BIM systems.
- Automatically creates a front, side, and top view (ortho photos) from the point cloud. Inuitive and easy to work with.
- Create floor plans & sections and measure areas, distances, volumes, and much more with just a few clicks.
- Compatible with all CAD & BIM systems
- Collect data from drones, terrestrial or SLAM laser scanners
- Process all data format with PointCab
Top Functionalities & Plugins
LAYOUTS & SECTIONS
Thanks to our Layout & Section module, it has never been easier to obtain fast and precise results from the point cloud – coloured as required and including difference comparison and analysis.
VECTORIZER
Thanks to the Semi-automatic Vectorizer, your sections and floor plans almost vectorise themselves!
4BIMm PLUGIN
The plugin for Archicad was developed in cooperation with long-time Archicad experts and is thus perfectly adapted to your needs as an Archicad user.
4REVIT PLUGIN
Bother no more with time-consuming importing, navigating, and measuring of point cloud data in Revit. Simply create your model and connect Revit with PointCab Origins. The 4Revit plugin automatically transfers all the 3D information needed to create walls, doors, windows, and other objects.
MANAGING DATA
DATA INPUT
• Aerial images
• Video
• Images taken by any hand camera
• Total stations & GNSS points
• Region geoid data
• *.dxf data
• Cube-a format (*.cx3d)
• Photogrammetry point cloud
• LIDAR point cloud
• XML surface data
• Orthophoto maps
• Underwater images
• Predefined camera parameters import
• Telemetry data import
• Camera offset support
• Cube-a format (*.cx3d)
• Bathymetry sonar cloud
DATA OUTPUT
• Orthophoto (*.Tiff, *.JPG, *.PNG, *KMZ, …)
• Textured 3D model (*.obj, …)
• Point cloud (*.e57, *.las, *.ply, …)
• Digital surface model (*.obj, *.xml)
• Regular/irregular grid mesh
• Contour lines (*.dxf, *.pdf, …)
• CAD drawings (*.dxf)
• Selected points (*.dxf, *.txt, …)
• Quick scketches (*.pdf, *jpg, *.png)
• Survey maps (*dxf, *.pdf, *.jpg, …)
• Camera parameters
• Undistorted images
